Cooling Features :
Type	Direct Cool
Capacity :
Gross Volume	268 Ltr.
Net Volume	254 Ltr.
Net Weight	61 ± 2 Kg
Gross Weight	66 ± 2 Kg
Performance :
Climatic Type (SN, N, ST, T)	N~ST
Rated Voltage/ Hz	220 ~ 240/ 50
Compressor Input Power (Watt)	V 02.01-132 V 03.01-118 V 03.02-118 V 04.01-127
Compressor Type	V 02.01-RSCR V 03.01-RSCR V 03.02-RSCR V 04.01-RSCR
Cooling Effect	Freezer Cabinet Less than -18℃ Refrigerator Cabinet 0℃ to +5℃
Energy Rating	5 star (BDS 1850:2012)
General Features :
Temperature Control (Electronic/ Mechanical)	Mechanical
Defrosting (Automatic/ Manual)	Manual
Reversible Door	No
Handle (Recessed/ Grip)	Recessed/ Grip
Lock	Yes
Refrigerant	V 02.01-R134a V 03.01-R600a V 03.02-R600a V 04.01-R600a
Condenser	Steel
Thermostat	RoHS Certified
Capillary	Copper
Polyurethane foam blowing agent	Cyclopentene [Eco-friendly (100% CFC & HCFC Free) Green Technology]
Recommended voltage stabilizer capacity	V 02.01-1000VA V 03.01,V 03.02-Low Voltage(140~260V) For V 03.01,V 03.02 - Wide Voltage Range (140Vac - 260Vac). Voltage stabilizer is not required. In case of voltages beyond this range, 1000VA is recommended. V 04.01-Low Voltage(150~260V) For V 04.01 - Wide Voltage Range (150Vac - 260Vac). Voltage stabilizer is not required. In case of voltages beyond this range, 1000VA is recommended.
Refrigerator Compartment :
Shelf (Material/ No.)	Wire/3
Door Pocket	GPPS/4
Interior Lamp	Yes
Vegetable Crisper	Yes
Vegetable Crisper Cover	Yes
Egg Tray	Yes
Freezer Compartment :
Shelf (Material/ No.)	Wire/3
Drawer	HIPS/5
Door Pocket	No
Interior Lamp	No
Net Dimensions :
Width/mm	545 mm
Depth/mm	630 mm
Height/mm	1800 mm
Packaging :
Width/mm	580 mm
Depth/mm	640 mm
Height/mm	1810 mm
Loading Capacity- 40HQ/ 40Ft/ 20Ft	97/ 72/ 36
