| Starting System | Electric Start |
| Battery : | |
| Battery Capacity | 12V, 18AH |
| Ignition : | |
| Ignition Mode | Compression Ignition System |
| Fuel : | |
| Fuel Tank capacity | 16L |
| Fuel Option | Diesel |
| Fuel Consumption | 2.0 L/Hr. at rated load |
| Time : | |
| Operating Time | 6 Hours Continuously at rated load |
| Weight : | |
| Net Weight | 154 Kg |
| Engine : | |
| Engine Type | Single cylinder; 4-stroke diesel engine |
| Engine Displacement | 474 cc |
| Engine Model | 188F |
| Engine oil capacity | 1.65 L |
| Cooling system | Air cooling |
| Shaft position | Horizontal |
| Load Capacity : | |
| Capacity Output (Rated) | 5000 Watt |
| Capacity Output (Maximum) | 5500 Watt |
| Frequency : | |
| Frequency in hertz | 50 Hz |
| Voltage : | |
| Rated output voltage | 220V |
| Speed : | |
| Speed per minute | 3000 RPM |
| Carton Dimension (mm) | |
| Length | 960 mm |
| Width | 560 mm |
| Height | 770 mm |
| Product Dimension (mm) | |
| Length | 880 mm |
| Width | 510 mm |
| Height | 660 mm |
| Weight (kg) | |
| Gross Weight | 165 kg |
| Net Weight | 150 kg |
